COB Small Pixel Pitch

COB Small Pixel Pitch
Details:
COB small pitch represents the pinnacle of LED small pitch technology, providing unparalleled clarity, seamless visual effects and excellent durability. The display adopts COB packaging, integrating LEDs directly onto the substrate, ensuring higher stability, better heat dissipation, and enhanced dust and moisture resistance.
Product Model:COB-Z
Module model (mm): PH0.62 / PH0.78 / PH0.93 / PH1.25 / PH1.56 / PH1.87
Box size (mm): 600X337.5
Circuit scheme:Common cathode circuit
Refresh rate (Hz):3840
Send Inquiry
Description
Send Inquiry

Ultra-High Resolution COB Small Pixel Pitch LED Displays



If you're searching for top-tier LED solutions that deliver crystal-clear visuals for your business or event needs, our COB Small Pixel Pitch displays stand out as an exceptional choice. As a leading manufacturer, we specialize in COB Small Pixel Pitch technology, which represents the pinnacle of LED small pitch innovation. This advanced approach provides unparalleled clarity, seamless visual effects, and outstanding durability, making it ideal for applications where every detail matters.

Our COB Small Pixel Pitch displays utilize Chip-on-Board (COB) packaging, where LEDs are integrated directly onto the substrate. This design ensures higher stability, superior heat dissipation, and enhanced resistance to dust and moisture. Whether you're looking to buy COB Small Pixel Pitch screens for conference rooms, control centers, or retail environments, you'll appreciate how this technology minimizes common issues like pixel failure and downtime, keeping your operations running smoothly.





Feature And Advantage

When considering where to purchase COB Small Pixel Pitch LED displays, it's essential to focus on the benefits that directly impact your user experience. Here's what sets our COB Small Pixel Pitch apart:



Wide Color Gamut: Our COB Small Pixel Pitch offers a broadcast-level 125% NTSC color gamut, delivering vibrant and accurate color reproduction that brings your content to life. This is perfect for customers seeking the best COB Small Pixel Pitch for high-definition video walls.
COB small pitch LED display solution001
Superior Protection: Built with dustproof, shockproof, knockproof, moisture-proof, anti-oxidation, and anti-static features, our COB Small Pixel Pitch ensures long-lasting performance in demanding settings. If you're exploring options to invest in durable COB Small Pixel Pitch solutions, this robust protection means fewer maintenance worries and more reliable uptime.
COB Small Pixel Pitch

Energy Efficiency: Featuring a common cathode circuit design, our COB Small Pixel Pitch consumes up to 40% less power than traditional displays. For businesses aiming to reduce operational costs, sourcing energy-saving COB Small Pixel Pitch LED screens like these can lead to significant savings over time.

COB package small pitch LED screen001
Ultra-High Resolution: With pixel pitches as fine as 0.9mm or smaller, our COB Small Pixel Pitch provides razor-sharp images that captivate audiences. Customers often inquire about high-resolution COB Small Pixel Pitch for indoor installations, and this level of detail makes it a go-to for immersive viewing experiences.
COB small pitch LED screen quotation001
Seamless Splicing: Achieve a completely smooth and borderless display with our COB Small Pixel Pitch, creating an immersive environment without distracting gaps. If you're ready to order seamless COB Small Pixel Pitch panels, this feature enhances everything from digital signage to command centers.
Small pitch COB display technology001



Why Choose Our COB Small Pixel Pitch for Your Projects?

As you evaluate suppliers for premium COB Small Pixel Pitch displays, consider how our products address real-world challenges. In high-traffic areas, the enhanced durability of COB Small Pixel Pitch reduces the risk of damage from accidental impacts or environmental factors. Plus, with its low power consumption, it's an eco-friendly option that aligns with sustainable business practices.

We understand that finding the right COB Small Pixel Pitch supplier can be overwhelming, so we've made the process straightforward. Our team is here to guide you through selecting the ideal COB Small Pixel Pitch model, whether for small-scale setups or large installations. Customers frequently ask about affordable COB Small Pixel Pitch options without compromising quality, and we're proud to offer competitive pricing on reliable, high-performance units.

11







Specifications



MiniCOB small pitch Z series

Module model (mm)

Z 0.62

Z 0.78

Z 0.93

Z 1.25

Z 1.56

Z 1.87

Module point spacing (mm)

0.62

0.78

0.9375

1.25

1.5625

1.875

Module Size (mm)

150x168.75

150x168.75

150x168.75

150x168.75

150x168.75

150x168.75

Module pixel

240x270

192x216

160x180

120x135

96x108

80x90

Packaging process

Full flip COB

Full flip COB

Full flip COB

Full flip COB

Full flip COB

Full flip COB

Module surface technology

Matte

Matte

Matte

Matte

Matte

Matte

Physical pixels (dot/㎡)

2560000

1638400

1137778

640000

409600

284444

Circuit scheme

Common cathode circuit

Common cathode circuit

Common cathode circuit

Common cathode circuit

Common cathode circuit

Common cathode circuit

Brightness (cd/㎡)

500-800

500-800

500-800

500-800

500-800

500-800

Refresh rate (Hz)

3840

3840

3840

3840

3840

3840

Color temperature (K)

9000

9000

9000

9000

9000

9000

surface hardness

4H

4H

4H

4H

4H

4H

Box size (mm)

600x337.5

600x337.5

600x337.5

600x337.5

600x337.5

600x337.5

Cabinet resolution (dots)

960x540

768x432

640x360

480x270

384x216

320x180

Box weight(kg)

8kg

8kg

8kg

8kg

8kg

8kg

Service life

≥100,000 hours

Pixel composition

RGB 3-in-1

Grayscale

14bit

Maximum power (W/㎡)

600-800W

Average power (W/㎡)

400-600W

Eliminate ghosting

Equipment

input voltage

AC100~240V 50/60HZ

Module input voltage

DC4.7~5V±0.2V

Environment

Temperature -10~40℃ Humidity 10%-90%





Application Areas



Advertising Media | Exhibition Display | Commercial Display | Government and Enterprise Image | Cultural Tourism Real Estate | Entertainment Culture



COB small pitch001







Highmight Service



COB small pitch LED video wall001



Demand assessment: We deeply analyze the specific needs of each project, whether it is a concert or an exhibition, to help customers choose the COB small pitch that best suits their needs and budget.

Tailored solutions: Our technical team provides customized display solutions based on the specific requirements of the venue, ensuring appropriate brightness and resolution to enhance the audience's visual experience.

Product display: We provide customers with product displays to help customers experience the display effect of the screen in advance.

Technical Assistance: Our team offers prompt on-site or remote support during installation to address any technical issues, ensuring the project proceeds without delays.



User Training: We provide comprehensive training on system operation, content management, and troubleshooting, equipping customers with the knowledge to effectively operate and maintain the equipment.

COB small pitch LED screen001

Regular Follow-up Visits: We regularly assess brightness, color consistency, and cable integrity to ensure optimal performance of your monitor.

24/7 Support: Our dedicated team is on call 24/7 to promptly address and resolve any issues.

Spare Parts and Maintenance: We offer fast replacement parts and repair services to minimize downtime and keep your screens running smoothly.

Customer Feedback Integration: We actively collect and analyze customer feedback to continuously improve and enhance our services.

COB small pitch display001







Certificate



COB small pitch display manufacturer001







FAQ



Q: What is a COB Small Pixel Pitch?

A: The COB Small Pixel Pitch uses advanced packaging technology, has a higher display density and a smaller pixel pitch, and is suitable for display environments that require high resolution.

Q: What are the advantages of COB Small Pixel Pitch?

A: COB technology provides better waterproof and dustproof performance, has a smaller pitch, and displays clearer picture quality.

Q: What application scenarios are COB Small Pixel Pitch for?

A: Indoor advertising/broadcasting and television studios/control rooms/high-end conference rooms.

Q: How is the display effect of COB Small Pixel Pitch?

A: COB Small Pixel Pitch provide more delicate and clearer pictures, especially suitable for close-up viewing.

Q: How durable is the COB small-pitch LED screen?

A: COB Small Pixel Pitch have higher impact resistance and longer service life due to the use of a more robust packaging process.

Q: Is the maintenance of COB Small Pixel Pitch difficult?

A: COB Small Pixel Pitch adopt a modular design and support front maintenance, making the maintenance and repair process more convenient.



Hot Tags: COB small pixel pitch, China COB small pixel pitch manufacturers, suppliers, factory, led crystal film screen, , flexible led display, flexible transparent led screen, LED Rental Display Rental for Indoor Events, Naked Eye 3D Display
